Features: When the power supply voltage is between 0.9 and 1.1 times the rated voltage, the solenoid valve should be able to open and close normally within the water pressure range of the solenoid valve. Sealing performance: The solenoid valve lasts for 30s under the action of water pressure of 0.02MPa, and the leakage is less than 0.1ml. Under the action of hydrostatic pressure 0.02MPa-0.8MPa, there is no leakage. Working life. When the hydrostatic pressure is 0.8 MPa and the rated voltage is 1.1 times, the working life solenoid valve is opened for 3 seconds and closed for 3 seconds, and lasts for 7 x 24 hours (about 100,000 times). The insulation resistance between the conductive part and the exposed conductive part is greater than 20MΩ5. Drawing strength: Apply 1 minute 10N pulling force on the lead-out line without loosening or breaking. Starting characteristics: 0.9 times rated voltage is applied across the solenoid valve coil at 0.8 MPa, and the solenoid valve should be opened and maintained. Specification: Condition: 100% Brand New Material: Brass Size: approx.8.5*3.5*7.3cm / 3.35*1.38*2.87in Rated working voltage: DC12V DC24V AC220V (Optional) Working current: 0.46A (DC12V) 0.24A (DC24V) 27mA (AC220V) Power: 5.2W (DC12V) 5.6W (DC24V) 5.6W (AC220V) Working pressure: 0.02 - 0.8Mpa (instantaneous to withstand maximum pressure of 1.75Mpa) Operating temperature: 0 - 80°C (low temperature) 0 - 120°C (high temperature) Coil resistance: 26Ω (DC12V) 100Ω (DC24V) Storage temperature: -20 - +80°C (no icing condition) Preservation humidity: 25% to 95%RH Package List: 1* Electric Solenoid Valve 1、When the power supply voltage is between 0.9 and 1.1 times the rated voltage, the solenoid valve should be able to open and close normally within the water pressure range of the solenoid valve. 2、Sealing performance: The solenoid valve lasts for 30s under the action of water pressure of 0.02MPa, and the leakage is less than 0.1ml. Under the action of hydrostatic pressure 0.02MPa-0.8MPa, there is no leakage. 3、Working life. When the hydrostatic pressure is 0.8 MPa and the rated voltage is 1.1 times, the working life solenoid valve is opened for 3 seconds and closed for 3 seconds, and lasts for 7 x 24 hours (about 100,000 times). 4、The insulation resistance between the conductive part and the exposed conductive part is greater than 20MΩ5. 5、Drawing strength: Apply 1 minute 10N pulling force on the lead-out line without loosening or breaking.
